8.1 Linear Momentum and Impulse

Understanding Linear Momentum and Impulse

Linear momentum describes how much "oomph" a moving object carries. It combines both mass and velocity into a single quantity, making it one of the most useful tools for analyzing collisions, explosions, and any situation where objects interact. Impulse connects force and time to changes in momentum, explaining why airbags save lives and why you bend your knees when landing a jump.

Momentum and the Mass-Velocity Relationship

Linear momentum is a vector quantity defined as:

$\vec{p} = m\vec{v}$

Because it's a vector, momentum has both magnitude and direction. The direction of momentum is always the same as the direction of velocity.

Momentum is directly proportional to both mass and velocity. A loaded truck moving at 20 m/s has far more momentum than a small car at the same speed, simply because of its greater mass. Likewise, a bullet is light, but its high velocity gives it significant momentum.

• Units: kg·m/s (equivalent to N·s)
• A 0.145 kg baseball thrown at 40 m/s has momentum $p = (0.145)(40) = 5.8 \text{ kg·m/s}$
• A 1500 kg car at 30 m/s has momentum $p = (1500)(30) = 45{,}000 \text{ kg·m/s}$

Calculating Linear Momentum

For a single object, plug mass and velocity into $\vec{p} = m\vec{v}$. Make sure your units are consistent (kg for mass, m/s for velocity).

For a system of objects, find the total momentum by vector addition:

$\vec{p}_{\text{total}} = \vec{p}_1 + \vec{p}_2 + \cdots + \vec{p}_n$

For 2D problems, break each momentum vector into x and y components and add them separately:

1. Find $p_x = mv_x$ and $p_y = mv_y$ for each object.
2. Sum all the x-components to get $p_{\text{total},x}$.
3. Sum all the y-components to get $p_{\text{total},y}$.
4. Combine using $p_{\text{total}} = \sqrt{p_x^2 + p_y^2}$ if you need the magnitude.

Because momentum is a vector, direction matters. Two objects moving toward each other have momenta that partially (or fully) cancel, while objects moving in the same direction have momenta that add.

Impulse and Momentum Change

Impulse ($\vec{J}$) measures how much a force changes an object's momentum. It's defined as:

$\vec{J} = \Delta\vec{p} = \vec{p}_f - \vec{p}_i$

The impulse-momentum theorem connects force, time, and momentum change:

$\vec{F}_{\text{avg}} \Delta t = \Delta\vec{p}$

This equation tells you something powerful: the same change in momentum can result from a large force over a short time or a small force over a long time. That tradeoff is the whole reason airbags and crumple zones work. They extend the collision time ($\Delta t$), which reduces the average force on the passengers for the same momentum change.

Think about catching a baseball. If you hold your hands rigid, the ball stops in a very short time, and the force stings. If you let your hands "give" and move backward with the ball, you increase $\Delta t$, and the force on your hands drops significantly.

Solving Impulse and Momentum Problems

Most problems in this section use one of these relationships:

• Impulse from force and time: $\vec{J} = \vec{F}_{\text{avg}} \Delta t$
• Impulse from momentum change: $\vec{J} = m(\vec{v}_f - \vec{v}_i)$
• Average force: $\vec{F}_{\text{avg}} = \frac{\Delta\vec{p}}{\Delta t}$
• Contact time: $\Delta t = \frac{\Delta\vec{p}}{\vec{F}_{\text{avg}}}$

Example: A 0.5 kg ball moving at 6 m/s hits a wall and bounces back at 4 m/s. The contact time is 0.02 s. Find the average force.

1. Choose a sign convention. Let the initial direction be positive.

2. Calculate $\Delta p = m(v_f - v_i) = 0.5(-4 - 6) = 0.5(-10) = -5 \text{ kg·m/s}$

3. Find average force: $F_{\text{avg}} = \frac{-5}{0.02} = -250 \text{ N}$

4. The negative sign means the force is directed opposite to the initial velocity, which makes sense for a wall pushing the ball back.

For closed systems (no external net force), total momentum is conserved: $\vec{p}_i = \vec{p}_f$. This principle is the foundation for analyzing collisions in the rest of this unit.
