8.2 Pressure

What is pressure in AP Physics 1?

Pressure is the perpendicular force pushing on a surface divided by the area it covers, written as $P = \frac{F_{\perp}}{A}$. It is a scalar, so it has magnitude but no direction. In a fluid, pressure increases with depth following $P = P_0 + \rho g h$, which is why deep water and dam bases experience higher pressure.

more resources to help you study

practice multiple choiceFRQ practice & scoringcheatsheetsscore calculator

Why This Matters for the AP Physics 1 Exam

Pressure shows up in Unit 8 (Fluids), which carries about 10 to 15 percent of the exam. This topic builds the foundation for buoyancy, fluid flow, and conservation laws in later fluids topics, so getting comfortable with pressure now pays off across the whole unit.

You will use these ideas to:

• Calculate pressure from a force on a surface and connect it to units like pascals (Pa).
• Explain why pressure depends on depth, not on the shape or width of the container.
• Distinguish absolute pressure from gauge pressure when justifying claims in writing.

Because fluids reasoning often requires written explanation and correct vocabulary, knowing the precise meanings of mass, weight, volume, density, and pressure helps you earn justification points and avoid losing them to vague language.

Key Takeaways

• Pressure is perpendicular force per unit area: $P = \frac{F_{\perp}}{A}$, measured in pascals ($\text{N}/\text{m}^2$).
• Pressure is a scalar. At any point in a fluid, it acts the same in all directions, though it still changes with depth.
• An incompressible fluid keeps constant volume and density even when the pressure on it changes.
• Gauge pressure in a fluid column is $P_{\text{gauge}} = \rho g h$, so pressure grows linearly with depth.
• Absolute pressure adds a reference pressure: $P = P_0 + \rho g h$, where $P_0$ is often atmospheric pressure.
• At the fluid surface ($h = 0$), gauge pressure is zero, but absolute pressure equals the reference (usually atmospheric) pressure.

Pressure on Surfaces

Force per Unit Area

Pressure measures how concentrated a force is when it is spread across a surface. The amount of pressure depends on both how hard you push and how much area the force acts on.

• Pressure $P$ equals the magnitude of the perpendicular force component $F_{\perp}$ divided by the surface area $A$: $P = \frac{F_{\perp}}{A}$.
• Increasing the force while keeping the area constant raises the pressure.
• Decreasing the area while keeping the force the same also raises the pressure.
• Pressure is measured in pascals (Pa), where $1 \text{ Pa} = 1 \text{ N}/\text{m}^2$.

This is why snowshoes have a large area to lower pressure on snow, while a knife edge has a small area to increase pressure for cutting.

Why Pressure Is a Scalar

Pressure is different from force because it has no direction.

• Pressure has magnitude only, with no specific orientation.
• Force, by contrast, is a vector with both magnitude and direction.
• At a given point in a fluid, the pressure does not depend on which way you face. It can still vary from place to place, such as with depth.

This scalar nature is why a submerged object feels pressure pushing in from all sides at once.

Incompressible Fluids

In the incompressible-fluid model used in AP Physics 1, a given amount of fluid keeps the same volume and density even when the pressure on it changes.

• Liquids like water, oil, and honey are treated as incompressible.
• Applying more pressure does not noticeably change their volume or density.
• Gases, in contrast, are compressible, so their volume and density change when pressure changes.

Fluid Pressure

Where Fluid Pressure Comes From

Fluid pressure comes from huge numbers of tiny collisions between fluid particles and a surface.

• The pressure a fluid exerts is the combined result of all the interactions between its particles and the surface they contact.
• Each particle pushes on the surface with a tiny force, and these add up to the total pressure.
• In a static fluid, the pressure at a given depth depends on the fluid's density, gravity, and depth.

Absolute vs Gauge Pressure

It helps to separate the total pressure (absolute) from the pressure measured relative to the atmosphere (gauge).

• Absolute pressure is the total pressure: $P = P_0 + \rho g h$, where $P_0$ is a reference pressure such as atmospheric pressure $P_{\text{atm}}$.
• Gauge pressure for a vertical fluid column is $P_{\text{gauge}} = \rho g h$.
• Positive gauge pressure means the pressure is above atmospheric.
• Negative gauge pressure means the pressure is below atmospheric.

A tire gauge reads gauge pressure, while a measurement of total pressure reports absolute pressure.

Pressure and Depth

Pressure in a fluid increases with depth because of the weight of the fluid above.

• Gauge pressure depends on fluid density $\rho$, gravitational acceleration $g$, and depth $h$: $P_{\text{gauge}} = \rho g h$.
• Pressure increases linearly with depth in a static fluid.
• At the surface ($h = 0$), gauge pressure is zero. The absolute pressure there equals the reference pressure, usually atmospheric pressure, not zero.
• Doubling the depth doubles the gauge pressure.

Notice that this depth relationship depends on depth and density, not on the container's shape or width. A narrow tube and a wide tank filled to the same depth have the same pressure at the bottom.

Practice Problem 1: Force per Unit Area

Solution: First, find the force the student exerts on the floor: $F = mg = 75 \text{ kg} \times 9.8 \text{ m/s}^2 = 735 \text{ N}$

a) Use $P = \frac{F}{A}$: $P = \frac{735 \text{ N}}{180 \text{ cm}^2} = \frac{735 \text{ N}}{0.018 \text{ m}^2} = 40{,}833 \text{ Pa}$

b) On one foot, the contact area is halved to 90 cm² or 0.009 m²: $P = \frac{735 \text{ N}}{0.009 \text{ m}^2} = 81{,}667 \text{ Pa}$

The pressure doubles when standing on one foot because the same force acts over half the area.

Practice Problem 2: Incompressible Fluid Properties

Solution: In the incompressible-fluid model, the water's volume and density are treated as unchanged when the pressure changes. So:

• The volume stays $0.020 \text{ m}^3$.
• The density stays $1,000 \text{ kg/m}^3$.

This is the key idea: for an incompressible fluid, the volume and density of a given amount of fluid stay constant no matter how the pressure changes. This model fits liquids like water and oil well in AP Physics 1.

Practice Problem 3: Vertical Fluid Pressure

Solution: a) The gauge pressure at the bottom is: $P_{gauge} = \rho gh = 1000 \text{ kg/m}^3 \times 9.8 \text{ m/s}^2 \times 2.5 \text{ m} = 24{,}500 \text{ Pa}$

b) The absolute pressure at the bottom is: $P_{absolute} = P_{atm} + P_{gauge} = 101{,}300 \text{ Pa} + 24{,}500 \text{ Pa} = 125{,}800 \text{ Pa}$

c) The force from the water above atmospheric pressure uses gauge pressure: $A = 3 \text{ m} \times 4 \text{ m} = 12 \text{ m}^2$ $F = P_{gauge} \times A = 24{,}500 \text{ Pa} \times 12 \text{ m}^2 = 294{,}000 \text{ N} = 2.94 \times 10^5 \text{ N}$

This is the added force from the water column beyond atmospheric pressure. It shows why dam walls are built thicker at the bottom: they must withstand greater force where the water pressure is highest.

How to Use This on the AP Physics 1 Exam

Problem Solving

• Start by writing $P = \frac{F_{\perp}}{A}$ and check that you use only the perpendicular force component.
• Convert areas to square meters before computing pressure in pascals. A common slip is leaving area in cm².
• For depth problems, decide whether the question wants gauge pressure ($\rho g h$) or absolute pressure ($P_0 + \rho g h$) before plugging in numbers.

Free Response

• When asked to explain, use precise vocabulary. Keep mass, weight, volume, density, and pressure distinct, since mixing them up can cost justification points.
• Justify claims about pressure with the depth relationship $P_{\text{gauge}} = \rho g h$, naming density, gravity, and depth as the factors that matter.
• If a problem compares containers of different shapes, state clearly that pressure depends on depth and density, not on container width or total fluid amount.

Common Trap

• Do not treat pressure as a vector. It has no direction, so you cannot add pressures like force vectors.
• Do not assume pressure is zero at the surface. The gauge pressure is zero there, but the absolute pressure equals atmospheric pressure.

Common Misconceptions

• Pressure is not the same as force. A small force on a tiny area can create high pressure, while a large force on a big area can create low pressure.
• Pressure does not have a direction. At one point in a fluid it acts the same in all directions, even though it changes with depth.
• Pressure at the bottom of a container does not depend on the container's shape or how wide it is. Two containers filled to the same depth with the same fluid have the same pressure at the bottom.
• Gauge pressure and absolute pressure are not interchangeable. Gauge pressure is measured relative to the atmosphere, while absolute pressure includes the reference pressure.
• An incompressible fluid does not change volume or density when you squeeze it. That constant-density assumption is part of the model, not something to ignore.
