12.8 Infrared Spectra of Some Common Functional Groups

2 min read•may 7, 2024

is a powerful tool for identifying in organic compounds. By analyzing absorption patterns, we can determine the presence of , , , and based on their unique vibrational frequencies.

like , , , and have distinct IR absorption patterns. These patterns help distinguish between similar structures and provide valuable information about a molecule's composition and bonding.

Infrared Spectroscopy and Functional Group Identification

IR absorptions of functional groups

Top images from around the web for IR absorptions of functional groups

  • ACTIVITY 3 | ORGANIC CHEMISTRY I View original

    Is this image relevant?

  • Infrared spectroscopy - Wikipedia View original

    Is this image relevant?

  • ACTIVITY 3 | ORGANIC CHEMISTRY I View original

    Is this image relevant?

1 of 3

Top images from around the web for IR absorptions of functional groups

  • ACTIVITY 3 | ORGANIC CHEMISTRY I View original

    Is this image relevant?

  • Infrared spectroscopy - Wikipedia View original

    Is this image relevant?

  • ACTIVITY 3 | ORGANIC CHEMISTRY I View original

    Is this image relevant?

1 of 3
  • Alkenes ([C=C](https://www.fiveableKeyTerm:C=C)[C=C](https://www.fiveableKeyTerm:C=C))
    • Weak absorption around 1600-1680 cm−1^{-1} caused by of the carbon-carbon double bond
    • Out-of-plane of the bonds at 800-1000 cm−1^{-1} (cis-2-butene)
  • Alkynes (C≡CC\equiv C)
    • Weak absorption at 2100-2260 cm−1^{-1} resulting from stretching of the carbon-carbon triple bond
    • Absence of signal at 3300 cm−1^{-1} which distinguishes from terminal alkynes (2-butyne)
  • Alcohols ([O−H](https://www.fiveableKeyTerm:O−H)[O-H](https://www.fiveableKeyTerm:O-H))
    • Strong, broad absorption at 3200-3600 cm−1^{-1} attributed to stretching of the O-H bond
    • Stretching of the bond at 1050-1150 cm−1^{-1} (ethanol)
  • Alkanes (C−HC-H)
    • Strong absorption at 2850-3000 cm−1^{-1} caused by stretching of the C-H bonds
    • Bending vibrations of the C-H bonds at 1450-1470 cm−1^{-1} and 1370-1390 cm−1^{-1} (propane)

Functional group analysis in IR spectra

  • Identify functional groups by their characteristic absorption frequencies
    • Compare observed peaks to known absorption ranges for each functional group (alcohols: 3200-3600 cm−1^{-1})
  • Absence of expected peaks indicates the absence of the corresponding functional group
    • No strong, broad absorption at 3200-3600 cm−1^{-1} suggests the compound lacks an O−HO-H group (hexane)
  • Presence of unexpected peaks may indicate the presence of additional functional groups
    • A strong peak at 1700-1750 cm−1^{-1} suggests the compound contains a carbonyl group (acetone)
  • Intensity of absorption peaks is related to the change in during

Carbonyl Compounds and Their IR Absorptions

Carbonyl compounds in IR spectroscopy

  • Aldehydes (R−CHOR-CHO)
    • Strong stretching of the [C=O](https://www.fiveableKeyTerm:C=O)[C=O](https://www.fiveableKeyTerm:C=O) bond at 1720-1740 cm−1^{-1}
    • Weak stretching of the C-H bond at 2700-2800 cm−1^{-1} and 2820-2900 cm−1^{-1} (propanal)
  • (R−CO−R′R-CO-R')
    • Strong stretching of the C=OC=O bond at 1705-1725 cm−1^{-1}
    • Absence of C-H stretching at 2700-2900 cm−1^{-1} which distinguishes from aldehydes (2-butanone)
  • Carboxylic acids (R−COOHR-COOH)
    • Strong, broad stretching of the O−HO-H bond at 2500-3300 cm−1^{-1}
    • Strong stretching of the C=OC=O bond at 1700-1730 cm−1^{-1}
    • Stretching of the C-O bond at 1210-1320 cm−1^{-1} (acetic acid)
  • Esters (R−COO−R′R-COO-R')
    • Strong stretching of the C=OC=O bond at 1735-1750 cm−1^{-1}
    • Stretching of the C-O bond at 1000-1300 cm−1^{-1}
    • Absence of O-H stretching which distinguishes from carboxylic acids (ethyl acetate)

Principles of Infrared Spectroscopy

  • Infrared spectroscopy is a type of that uses in the infrared region
  • It measures the absorption of infrared light by molecules, which causes molecular vibrations
  • is a modern technique that improves the quality and speed of IR spectra collection
