10.2 Laws of Thermodynamics

Laws of Thermodynamics

The laws of thermodynamics govern how energy moves, changes form, and behaves in physical systems. They set the ground rules for everything from car engines to chemical reactions to why your coffee cools down on the counter. This section covers all four laws (yes, there's a "zeroth" law), along with entropy, energy conservation, and how heat engines put these principles to work.

more resources to help you study

practice questions

Laws of Thermodynamics

Temperature Equilibrium (Zeroth Law)

The zeroth law came after the first and second laws historically, but it's so fundamental that it got placed before them.

It states: if system A is in thermal equilibrium with system C, and system B is also in thermal equilibrium with system C, then A and B are in thermal equilibrium with each other.

This might sound obvious, but it's what allows temperature to exist as a measurable quantity. Without it, thermometers wouldn't work. When you place a thermometer in water, the thermometer reaches thermal equilibrium with the water. You then read the thermometer's temperature and trust that it matches the water's temperature. That chain of reasoning depends entirely on the zeroth law.

First Law: Conservation of Energy

The first law states that energy cannot be created or destroyed, only converted from one form to another. The total energy of an isolated system stays constant.

Mathematically:

$\Delta U = Q - W$

• $\Delta U$ = change in internal energy of the system
• $Q$ = heat added to the system
• $W$ = work done by the system

Think of it like a bank account for energy. Heat flowing in is a deposit, work done by the system is a withdrawal, and $\Delta U$ is the change in your balance. Energy can shift between forms (kinetic, potential, thermal, chemical), but the total never changes.

Second Law: Entropy and Irreversibility

The second law introduces entropy, a measure of disorder or randomness in a system. It states that the total entropy of an isolated system always increases over time (or stays the same in an idealized reversible process, which never truly happens in reality).

This law has several practical consequences:

• Heat flows spontaneously from hot objects to cold objects, never the reverse. Getting heat to flow "uphill" (like in a refrigerator) requires external work.
• No heat engine can convert 100% of thermal energy into useful work. Some energy is always "lost" as waste heat.
• Irreversible processes (mixing gases, friction, heat transfer across a temperature difference) always increase the total entropy of the universe.

Entropy explains why processes go in one direction. An egg breaks but doesn't unbreak. Your coffee cools to room temperature but never spontaneously heats back up. These are all consequences of the second law.

Third Law: Absolute Zero

The third law states that the entropy of a perfect crystal at absolute zero ($0 \text{ K}$, or $-273.15°\text{C}$) is exactly zero. At that temperature, atoms would be in a single, perfectly ordered arrangement with no randomness at all.

Two key points here:

• It's impossible to actually reach absolute zero. You can get extremely close, but each step closer requires more and more effort. The approach is asymptotic: you can always halve the remaining distance but never arrive.
• Even near absolute zero, quantum mechanics predicts a tiny residual energy called zero-point energy. Molecular motion doesn't completely stop; it reaches the lowest energy state allowed by quantum mechanics.

Energy and Entropy

Conservation of Energy in Practice

Energy conservation (from the first law) applies everywhere, from collisions between billiard balls to chemical reactions in a battery. The total energy before a process equals the total energy after, as long as you account for all forms:

• Kinetic energy (energy of motion)
• Potential energy (energy stored due to position or configuration)
• Thermal energy (internal energy related to temperature)
• Chemical energy (energy stored in molecular bonds)

When you rub your hands together, kinetic energy converts to thermal energy through friction. When gasoline burns in an engine, chemical energy converts to thermal energy and then to mechanical work. The first law guarantees the books always balance.

Entropy as a Measure of Disorder

Entropy quantifies how many different microscopic arrangements (called microstates) could produce the same macroscopic state you observe. The Boltzmann equation expresses this:

$S = k_B \ln W$

• $S$ = entropy
• $k_B$ = Boltzmann constant ($1.38 \times 10^{-23} \text{ J/K}$)
• $W$ = number of microstates

A system with more possible microstates has higher entropy. For example, when you drop a dye tablet into water, there are vastly more ways for the dye molecules to be spread throughout the water than clumped together. So the dye disperses, entropy increases, and the process is irreversible in practice.

Thermal Equilibrium

Thermal equilibrium is the state where two objects in contact reach the same temperature, and net heat flow between them stops.

• Heat always transfers from the hotter object to the cooler one until their temperatures match.
• The rate of heat transfer depends on the temperature difference between the objects and the thermal conductivity of the materials involved. A large temperature gap and a highly conductive material (like metal) mean faster transfer.
• Once equilibrium is reached, energy still moves back and forth at the molecular level, but the net flow is zero. This is sometimes called dynamic equilibrium at the microscopic scale.

Heat Engines and Efficiency

How Heat Engines Work

A heat engine is any device that converts thermal energy into mechanical work. Every heat engine operates between two energy reservoirs in a repeating cycle:

1. A hot reservoir (the heat source) supplies thermal energy at a high temperature.
2. The engine absorbs some of that heat and converts part of it into useful work.
3. The remaining energy is expelled as waste heat into a cold reservoir (the heat sink).
4. The cycle repeats.

Real-world examples include steam turbines in power plants (external combustion), car engines (internal combustion), and jet engines. All of them follow this same basic cycle, and none of them can escape the efficiency limits set by the second law.

Measuring Efficiency

Efficiency tells you what fraction of the input heat actually becomes useful work:

$\eta = \frac{W_{out}}{Q_{in}}$

The second law sets a hard ceiling on efficiency. Even a theoretically perfect engine (called a Carnot engine, with no friction or other irreversibilities) can't convert all heat into work. The Carnot efficiency depends only on the temperatures of the two reservoirs:

$\eta_{max} = 1 - \frac{T_c}{T_h}$

• $T_c$ = temperature of the cold reservoir (in Kelvin)
• $T_h$ = temperature of the hot reservoir (in Kelvin)

For example, if a steam engine operates between a hot reservoir at $500 \text{ K}$ and a cold reservoir at $300 \text{ K}$:

$\eta_{max} = 1 - \frac{300}{500} = 1 - 0.6 = 0.4$

That's a maximum of 40% efficiency. Real engines fall well below this due to friction, heat losses, and other irreversibilities. A typical car engine, for instance, runs at roughly 20–25% efficiency. This is why improving engine efficiency matters so much for energy conservation and reducing waste heat.

Notice what the Carnot equation tells you: the bigger the temperature difference between the hot and cold reservoirs, the higher the maximum efficiency. If $T_c$ could somehow reach $0 \text{ K}$, efficiency would be 100%, but the third law tells you that's impossible.
