9.8 Find the Area of a Polar Region or the Area Bounded by a Single Polar Curve

To find the area enclosed by a polar curve $r=f(\theta)$ from $\theta=a$ to $\theta=b$, use $A = \frac{1}{2}\int_a^b [f(\theta)]^2\,d\theta$. The hard part is usually not the integral itself but choosing the correct bounds, simplifying with trig identities, and using symmetry to keep the work clean. For AP Calculus BC, sketch the polar curve first so the bounds match the region you want.

Polar area is a BC-only topic in Unit 9, and on the exam you may set up and evaluate these integrals either by hand or with a graphing calculator, so be ready to explain your bounds either way.

Setting Up the Polar Area Integral

• The polar area formula is $A = \frac{1}{2}\int_{a}^{b}[f(\theta)]^2\,d\theta$, where $r=f(\theta)$.
• This comes from summing tiny circular sectors; the area of one sector is $\frac{1}{2}r^2\,\Delta\theta$.
• Choosing the right $\theta$ bounds is the most common place to lose points. Often you find them where $r=0$ or where the curve completes one loop.
• Use symmetry to shrink the interval, then multiply back. For example, integrate half a region and double it.
• Simplify squared trig terms with identities like $\cos^2\theta=\frac{1+\cos(2\theta)}{2}$ before integrating.
• Sketch the curve first so you know how many loops or petals you are actually enclosing.

Understanding Polar Coordinates

Polar coordinates locate a point using a radius $r$ and an angle $\theta$ instead of horizontal and vertical distances. This is handy for curves like circles, spirals, cardioids, and rose petals that are awkward to write in $x$ and $y$.

To build the area formula, start with a circular sector (a pizza slice). A sector with radius $r$ and central angle $\theta$ (in radians) has area $\frac{1}{2}r^2\theta$.

Where the Area Formula Comes From

To find the area $A$ enclosed by a polar curve $r=f(\theta)$ from $\theta=a$ to $\theta=b$, slice the region into thin sectors. Each thin sector has angle $d\theta$ and radius $f(\theta)$, so its area is $\frac{1}{2}[f(\theta)]^2\,d\theta$. Adding up all the slices gives the definite integral:

$A = \frac{1}{2}\int_{a}^{b}[f(\theta)]^2\,d\theta$

This is the same limit-of-a-Riemann-sum idea you use for area in rectangular coordinates. The only change is that the building block is a sector, not a rectangle.

---

Worked Examples

A Simple Circle

Find the area inside the circle $r=2\cos(\theta)$ over the range $0\leq\theta\leq\pi$.

1. Set up the integral. Square the radius and integrate over the given range: $A = \frac{1}{2}\int_{0}^{\pi}(2\cos(\theta))^2\,d\theta$
2. Simplify. Expand the square: $A = 2\int_{0}^{\pi}\cos^2(\theta)\,d\theta$
3. Solve. Use the identity $\cos^2(\theta)=\frac{1+\cos(2\theta)}{2}$: $A=2\left[\frac{\theta}{2}+\frac{\sin(2\theta)}{4}\right]\Big\vert_0^\pi=\pi$

The area inside $r=2\cos(\theta)$ over $0\leq\theta\leq\pi$ is $\pi$ square units.

One Petal Using Symmetry

Calculate the area of one petal of the rose curve $r=\sin(2\theta)$.

1. Find the range for one petal. The curve $r=\sin(2\theta)$ traces one petal as $\theta$ goes from $0$ to $\frac{\pi}{2}$, since $r=0$ at both ends.
2. Set up the integral. Apply the polar area formula over that interval: $A = \frac{1}{2}\int_{0}^{\frac{\pi}{2}}(\sin(2\theta))^2\,d\theta$
3. Solve. Use $\sin^2(2\theta)=\frac{1-\cos(4\theta)}{2}$: $A=\frac{1}{2}\left[\frac{\theta}{2}-\frac{\sin(4\theta)}{8}\right]\Big\vert_0^\frac{\pi}{2}=\frac{\pi}{8}$

The area of one petal of $r=\sin(2\theta)$ is $\frac{\pi}{8}$ square units.

---

Choosing Bounds and Setting Up Polar Area

Problem Solving:

• Read the curve first. Decide whether you want the area of the whole region, one loop, or one petal, then pick bounds that enclose exactly that.
• Find bounds by solving $r=0$ for loop and petal problems, or by tracing one full pass of the curve.
• Square the radius before integrating. Do not forget the $\frac{1}{2}$ out front.
• Use trig identities to turn $\sin^2$ and $\cos^2$ into something you can integrate.
• If the region is symmetric, integrate over half and multiply, but make sure the half you pick actually matches the full region.

Common Trap: Watch out for limacons with an inner loop, like $r=1+2\sin(\theta)$. Squaring the radius and integrating from $0$ to $2\pi$ does not always give the "obvious" enclosed region, because the curve can cross itself. A cardioid like $r=3+3\sin(\theta)$ has no inner loop and is traced once over $0\le\theta\le2\pi$, so the full integral gives its area. Sketch the curve and confirm which area the problem wants before locking in your bounds.

---

Practice Problem

Calculate the area enclosed by the polar curve $r=3+3\sin(\theta)$ over the interval $0\le\theta\le2\pi$.

1. Sketch the curve. For $r=3+3\sin(\theta)$, this is a cardioid-type limacon. Sketching first tells you how the region is shaped and where it is symmetric.

2. Set up the integral. Apply the polar area formula over the full interval: $A=\frac{1}{2}\int_{0}^{2\pi}(3+3\sin(\theta))^2\,d\theta$

3. Expand the square. $A=\frac{1}{2}\int_{0}^{2\pi}(9+18\sin(\theta)+9\sin^2(\theta))\,d\theta$

4. Solve each piece.

   • $\int_{0}^{2\pi}9\,d\theta =9\theta\big\vert_0^{2\pi}=18\pi$
   • $\int_{0}^{2\pi}18\sin(\theta)\,d\theta =-18\cos(\theta)\big\vert_0^{2\pi}=0$
   • $\int_{0}^{2\pi}9\cdot\frac{1-\cos(2\theta)}{2}\,d\theta=\frac{9}{2}\left(\theta-\frac{\sin(2\theta)}{2}\right)\Big\vert_0^{2\pi}=9\pi$

5. Combine. $A=\frac{1}{2}(18\pi+0+9\pi)=\frac{27\pi}{2}$

The area enclosed by $r=3+3\sin(\theta)$ is $\frac{27\pi}{2}$ square units.

---

Common Misconceptions

• Misconception: The polar area formula does not include a factor of one-half.
  Actually: The polar area formula is $\frac{1}{2}\int r^2\,d\theta$, not $\int r^2\,d\theta$. Dropping the one-half halves your area.
• Misconception: You should integrate $r$ instead of $r^2$.
  Actually: You must square the radius before integrating. Integrating $f(\theta)$ alone is not an area.
• Misconception: You should always use bounds from $0$ to $2\pi$.
  Actually: Many curves complete a full loop or a single petal over a smaller interval. Going to $2\pi$ can double-count area or trace the curve more than once.
• Misconception: You can set up bounds without sketching the curve.
  Actually: Setting up bounds without sketching the curve leads to wrong intervals, especially for roses and limacons with inner loops.
• Misconception: Polar area is calculated like rectangular area.
  Actually: You are summing sectors, not rectangles, so the setup uses $r^2$ and $d\theta$, not a height-times-width strip.
