Practice FRQ 1 of 201/20

1. An insulating sphere of radius

R = 0.20\ \text{m}

is centered at the origin. The sphere has a spherical cavity of radius

a = 0.050\ \text{m}

that is concentric with the sphere, as shown in Figure 1. The insulating material (the region

a < r < R

) contains a uniform volume charge density

\rho = +6.0\times10^{-6}\ \text{C/m}^3

. The cavity (the region

r < a

) is empty. Ignore edge effects and assume electrostatic equilibrium.

Figure 1. Insulating sphere with concentric spherical cavity and uniform volume charge density in the insulating material.

A clean black-and-white cross-sectional diagram (a 2D slice through the center) of two concentric circles representing a sphere with a concentric spherical cavity.

Layout and geometry (must be perfectly concentric):
- Draw a large circle centered in the middle of the figure. This is the outer surface of the insulating sphere.
- Draw a smaller circle with the exact same center as the large circle. This is the cavity boundary.
- The common center point is explicitly marked with a small solid dot and labeled "origin" directly next to it.

Numeric labels that must appear exactly as text:
- Near the boundary of the large circle, place the label "R = 0.20 m" with a thin leader line pointing to the outer circle.
- Near the boundary of the small circle, place the label "a = 0.050 m" with a thin leader line pointing to the inner circle.

Region identification and charge density (must be unambiguous):
- The annular region between the two circles (the material for which a < r < R) is filled with uniform light-gray shading (or evenly spaced hatch marks) to indicate the charged insulating material.
- Inside this shaded annulus, include the text label "uniform volume charge density" on one line and directly below it "ρ = +6.0×10^−6 C/m^3".
- The central cavity region (inside the smaller circle, r < a) is left completely white (no shading) and labeled "empty cavity (r < a)".

Radial coordinate indication:
- Draw a single straight radius line from the origin to the right, ending exactly at the outer circle. Label this line "r" above the line.
- On this same radius line, mark the point where it crosses the cavity boundary with a small tick mark and place the text "r = a" next to that tick.
- Mark the point where it reaches the outer surface with a small tick mark and place the text "r = R" next to that tick.

Styling constraints:
- Circle outlines are solid black, with the outer circle slightly thicker than the inner circle.
- No extraneous objects, no 3D perspective, no grid, no background texture.
- Only the labels specified above appear as text.

Figure 2. Axes for graphing the electric field magnitude E as a function of radial distance r.

A blank set of Cartesian axes prepared for sketching E versus r.

Axes and formatting (all of these must be present):
- Horizontal axis label: "r (m)" centered below the axis.
- Vertical axis label: "E (N/C)" centered along the vertical axis.
- The axes intersect at the left end of the horizontal axis, and that intersection is labeled with the number "0" (the origin label must be visible).
- Arrowheads are drawn at the positive end of the r-axis (pointing right) and at the positive end of the E-axis (pointing up).

Exact x-axis range and ticks (must be numeric):
- The r-axis starts at "0" at the origin and extends to "0.30" at the far right end.
- Place visible tick marks and numeric labels at increments of 0.05 m: "0.05", "0.10", "0.15", "0.20", "0.25", "0.30".
- The tick at "0.05" is additionally labeled "a = 0.050" directly beneath that tick (so the axis shows both the numeric tick and the symbolic boundary).
- The tick at "0.20" is additionally labeled "R = 0.20" directly beneath that tick.

Exact y-axis range and ticks (must be numeric, even though the curve is student-sketched):
- The E-axis runs from "0" at the origin up to "8.0×10^4" at the top.
- Place visible tick marks and numeric labels every "2.0×10^4": "2.0×10^4", "4.0×10^4", "6.0×10^4", "8.0×10^4".

Guide markers for region changes (must be explicit visual guides):
- Draw a faint vertical dashed guide line through the tick at r = a (0.05 m), extending from the x-axis upward to near the top of the plotting area.
- Draw a faint vertical dashed guide line through the tick at r = R (0.20 m), extending from the x-axis upward to near the top of the plotting area.
- Under the x-axis, centered between 0 and a, add the small text "Region: r < a".
- Under the x-axis, centered between a and R, add the small text "Region: a < r < R".
- Under the x-axis, centered between R and 0.30 m, add the small text "Region: r > R".

No plotted curve:
- Do not draw any E(r) curve on these axes; this figure is axes only.
- No gridlines (other than the two dashed vertical guides at r = a and r = R). No title.

i. Using Gauss's law, derive an expression for the magnitude

E(r)

of the electric field as a function of the radial distance

r

from the center for each of the three regions

0 ≤ r < a

a < r < R

, and

r > R

. Express your answers in terms of

\rho

a

R

r

, and physical constants, as appropriate.

ii. Derive an expression for the potential difference

\Delta V = V(a) - V(R)

. Begin your derivation by writing a fundamental physics principle or an equation from the reference information, and use your result from part A(i). Express your answer in terms of

\rho

a

R

, and physical constants, as appropriate.

iii. On the axes shown in Figure 2, sketch a graph of the magnitude of the electric field

E

as a function of

r

from

r = 0

to a position that is outside the sphere (past

r = R

). Clearly indicate any changes in functional form at

r = a

and

r = R

A linear dielectric material with dielectric constant

\kappa = 4.0

is inserted so that it completely fills the cavity region

0 ≤ r < a

, as shown in Figure 3. The charge density

\rho

in the insulating material remains uniform and unchanged.

B. Derive an expression for the electric flux

\Phi_E

through a spherical Gaussian surface of radius

r_g = 0.030\ \text{m}

(which lies entirely within the dielectric-filled cavity). Express your answer in terms of

\rho

a

r_g

\kappa

, and physical constants, as appropriate. Begin your derivation by writing a fundamental physics principle or an equation from the reference information.

Figure 3. Same geometry as Figure 1, with the cavity filled by a linear dielectric of dielectric constant κ.

A clean black-and-white cross-sectional diagram of the same two concentric circles as Figure 1, with identical geometry and the same center at the origin.

Layout and geometry (must match Figure 1 exactly):
- Draw a large circle centered in the middle of the figure, representing the outer radius of the sphere.
- Draw a smaller concentric circle sharing the exact same center, representing the cavity boundary.
- Mark the shared center with a small solid dot and label it "origin".

Numeric labels that must appear exactly as text:
- Outer boundary label with leader line: "R = 0.20 m" pointing to the outer circle.
- Inner boundary label with leader line: "a = 0.050 m" pointing to the inner circle.

Material regions and labels:
- The annular region between the two circles (a < r < R) is filled with uniform light-gray shading (or evenly spaced hatch marks) and labeled inside the annulus with: "insulating material" and on the next line "ρ = +6.0×10^−6 C/m^3".
- The central region inside the smaller circle (r < a) is filled with a distinct pattern from the annulus (for example, a different hatch direction or dotted fill) to indicate a different material.
- Inside the cavity region, place the text label "linear dielectric" and directly below it "dielectric constant κ".

Radial coordinate indication (same as Figure 1):
- Draw a radius line from the origin to the right, ending at the outer circle and labeled "r".
- Place a tick mark where the radius crosses the inner circle labeled "r = a".
- Place a tick mark at the outer circle labeled "r = R".

Styling constraints:
- Outer circle outline slightly thicker than inner circle outline.
- No 3D perspective, no extra objects, no field lines, no grid.
- Only the labels specified above appear as text.
