1.3 Structural idealization and modeling
4 min read•august 9, 2024
and simplify complex structures for analysis. Engineers use assumptions and simplified models to focus on critical aspects, balancing accuracy and efficiency. This process involves identifying key components, load paths, and choosing appropriate model complexity.
Fundamental assumptions like linear elasticity and small deformations form the basis of structural analysis. Engineers compare 2D and 3D modeling approaches, selecting the most suitable representation based on geometry, loading conditions, and required accuracy.
Model Simplification
Simplifying Complex Structures
Top images from around the web for Simplifying Complex Structures
Assignment_4 View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
Assignment_4 View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
1 of 3
Top images from around the web for Simplifying Complex Structures
Assignment_4 View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
Assignment_4 View original
Is this image relevant?
Simplifying complex data | UCL Science blog View original
Is this image relevant?
1 of 3
- Simplified models reduce complex structures to manageable representations for analysis
- Assumptions form the basis of structural idealization, allowing engineers to focus on critical aspects
- represent structures in two dimensions, suitable for planar analysis (beams, trusses)
- capture spatial behavior, necessary for complex geometries (space frames, shells)
- process involves identifying key structural components and load paths
- Engineers balance accuracy and computational efficiency when choosing model complexity
Fundamental Assumptions in Structural Analysis
- Linear elastic behavior assumes materials return to original shape after load removal
- applies when displacements are small compared to overall structure size
- presumes structure remains at rest under applied loads
- allows combining effects of multiple loads linearly
- Homogeneous assume uniform characteristics throughout structural elements
- Plane sections remain plane after deformation, crucial for beam theory
Comparing 2D and 3D Modeling Approaches
- 2D models offer simplicity and faster analysis for planar structures (building frames, bridges)
- 3D models provide comprehensive behavior analysis, capturing torsional effects and out-of-plane loading
- 2D idealizations include plane stress, plane strain, and axisymmetric models
- 3D representations encompass , , and space frame formulations
- Model dimensionality selection depends on structure geometry, loading conditions, and required accuracy
- combine 2D and 3D elements to optimize analysis efficiency (floor diaphragms with 3D columns)
Boundary Conditions
Types of Structural Supports
- define constraints on structural movement and rotation
- allow rotation but prevent translation (bridge bearings)
- restrict both rotation and translation (column bases in moment frames)
- permit translation in one direction while preventing movement in others (expansion joints)
- provide partial restraint, modeled with springs (soil-structure interaction)
- allow relative rotation between connected elements (pin-connected trusses)
- Support conditions significantly influence structural behavior and load distribution
Modeling Connections in Structural Systems
- Connections transfer forces between structural elements
- maintain constant angles between connected members (welded joints)
- allow relative rotation between members (bolted truss connections)
- exhibit partial moment transfer (partially restrained beam-column joints)
- affects overall structural behavior and load distribution
- Proper modeling of connections ensures accurate representation of force transfer mechanisms
- Engineers must consider connection flexibility in analysis for realistic structural response prediction
Implementing Boundary Conditions in Analysis
- Boundary conditions translate to mathematical constraints in structural equations
- Displacement method enforces known displacements at supports ( for fixed support)
- Force method applies reaction forces at constrained degrees of freedom
- Penalty method introduces large stiffness values to approximate rigid constraints
- Lagrange multipliers enforce exact constraint conditions without numerical ill-conditioning
- Proper boundary condition implementation ensures solution uniqueness and stability
- Sensitivity analysis assesses the impact of boundary condition variations on structural response
Element Idealization
Idealized Structural Elements
- carry axial loads only, assuming pinned connections (roof trusses, bridge members)
- resist bending, shear, and axial forces (floor joists, cantilever beams)
- combine beam and truss behavior for space frame analysis
- model thin, flat structures subjected to out-of-plane loading (concrete slabs)
- Shell elements represent curved surfaces, combining membrane and bending behavior (domes, pressure vessels)
- Solid elements model three-dimensional stress states in thick structures (dams, machine parts)
- Element selection depends on structural behavior, geometry, and analysis requirements
Degrees of Freedom in Structural Analysis
- represent independent displacements and rotations at nodes
- Truss elements typically have 3 DOF per node in 3D space (translations only)
- Beam elements in 2D have 3 DOF per node (2 translations, 1 rotation)
- Frame elements in 3D space have 6 DOF per node (3 translations, 3 rotations)
- Plate and shell elements may have 5 or 6 DOF per node, depending on formulation
- Solid elements usually have 3 translational DOF per node
- Number of DOF affects computational complexity and solution time
- Reduced DOF formulations (e.g., Mindlin plate theory) balance accuracy and efficiency
Element Formulation and Behavior
- describe displacement field within elements
- uses same functions for geometry and displacements
- link nodal displacements to internal strains
- relate strains to stresses based on material properties
- Element stiffness matrices derived from energy principles or virtual work
- Higher-order elements provide improved accuracy at the cost of increased complexity
- Special elements address specific structural behaviors (crack tip elements, contact elements)
- Element technology advancements continually improve analysis capabilities and efficiency
