8.4 Describing Function Method

3 min read•july 30, 2024

can be tricky to analyze, but the method offers a handy shortcut. It's like having a secret decoder ring that turns complex nonlinear elements into simpler linear approximations, making it easier to predict system behavior.

This method is especially useful for spotting limit cycles – those pesky self-sustained oscillations that can pop up in nonlinear systems. By breaking down the system into linear and nonlinear parts, we can predict when these oscillations might occur and what they'll look like.

Describing Function Method

Overview and Applications

Top images from around the web for Overview and Applications

  • pid - Non linear control system? - Robotics Stack Exchange View original

    Is this image relevant?

  • pid - Non linear control system? - Robotics Stack Exchange View original

    Is this image relevant?

1 of 2

Top images from around the web for Overview and Applications

  • pid - Non linear control system? - Robotics Stack Exchange View original

    Is this image relevant?

  • pid - Non linear control system? - Robotics Stack Exchange View original

    Is this image relevant?

1 of 2
  • The describing function method is an approximation technique used to analyze nonlinear systems by representing the nonlinear element with an equivalent linear gain
  • It is particularly useful for predicting the existence and characteristics of limit cycles (self-sustained oscillations) in nonlinear systems
  • The describing function is a complex-valued function that depends on the amplitude and frequency of the input signal to the nonlinear element
  • Applications of the describing function method include:
    • Analyzing nonlinear control systems
    • Studying the stability of nonlinear systems
    • Designing controllers for nonlinear systems

Describing Functions for Nonlinearities

Saturation Nonlinearity

  • occurs when the output of a system is limited to a maximum or minimum value, regardless of the input magnitude
  • The describing function for a saturation nonlinearity is a function of the input amplitude and the saturation limits
  • For a symmetric saturation with limits +/- L, the describing function is:
    • N(A)=(2L/πA)∗(sin−1(A/L)+(A/L)√(1−(A/L)2))N(A) = (2L/πA) * (sin⁻¹(A/L) + (A/L)√(1 - (A/L)²)), where A is the input amplitude
  • Example: A motor control system with a maximum voltage limit (saturation) of +/- 12V

Dead-zone Nonlinearity

  • occurs when the output of a system remains zero for a range of input values around zero
  • The describing function for a dead-zone nonlinearity is a function of the input amplitude and the dead-zone width
  • For a symmetric dead-zone with width 2D, the describing function is:
    • N(A)=(2/π)∗(√(1−(D/A)2)+(D/A)sin−1(D/A))N(A) = (2/π) * (√(1 - (D/A)²) + (D/A)sin⁻¹(D/A)) for A > D
    • N(A)=0N(A) = 0 for A ≤ D
  • Example: A hydraulic valve with a dead-zone of +/- 0.5 mm around the neutral position

Limit Cycle Prediction

Conditions for Limit Cycles

  • Limit cycles are self-sustained oscillations that can occur in nonlinear systems, characterized by a closed trajectory in the phase plane
  • To predict limit cycles using the describing function method, the system is represented as a linear part (transfer function) and a nonlinear part (describing function)
  • The condition for the existence of a is given by the equation:
    • G(jω)N(A)=−1G(jω)N(A) = -1, where G(jω)G(jω) is the transfer function of the linear part and N(A)N(A) is the describing function of the nonlinear element

Solving for Limit Cycle Characteristics

  • Solving the limit cycle condition equation for the amplitude A and frequency ω provides the predicted characteristics of the limit cycle
  • The stability of the predicted limit cycle can be determined by analyzing the phase of G(jω)N(A)G(jω)N(A) in the vicinity of the solution
  • Example: A nonlinear system with a saturation nonlinearity in the actuator

Describing Function Limitations

Assumptions and Approximations

  • The describing function method is an approximation technique and has several limitations and assumptions that should be considered when applying the method
  • The method assumes that the nonlinearity is time-invariant and memoryless, meaning that the output depends only on the current input value
  • The input to the nonlinear element is assumed to be a sinusoidal signal, which may not always be the case in practical systems

Accuracy and Applicability

  • The method does not account for harmonics generated by the nonlinearity, which can lead to inaccuracies in the analysis
  • The describing function method is most accurate when the linear part of the system has low-pass filter characteristics, attenuating the higher harmonics generated by the nonlinearity
  • The method may not provide accurate results for systems with multiple nonlinearities or strong interactions between the nonlinear elements
  • Example: A system with a combination of saturation and dead-zone nonlinearities may require more advanced analysis techniques

Key Terms to Review (20)

Asymptotic stability: Asymptotic stability refers to a property of a dynamic system where, if the system is perturbed from its equilibrium point, it will return to that point over time, ultimately converging to it as time approaches infinity. This concept is critical in understanding how systems respond to disturbances and is closely tied to system behavior, including feedback mechanisms and response characteristics.
Bifurcation: Bifurcation refers to a phenomenon in which a slight change in the parameters of a system causes a sudden qualitative change in its behavior or structure. This concept is particularly relevant when analyzing nonlinear systems, where small variations can lead to entirely different outcomes, illustrating the complex nature of these systems. Bifurcations can be seen in various contexts, from the dynamics of phase planes to feedback control, and they play a critical role in understanding how nonlinear control systems function.
Dead-zone nonlinearity: Dead-zone nonlinearity is a type of nonlinear behavior in dynamic systems where there is a range of input values for which there is no output response. This means that small inputs fall within a 'dead zone' and do not produce any effect, making the system unresponsive until a certain threshold is crossed. This characteristic impacts the system's behavior and stability, influencing how it responds to various signals and inputs.
Describing Function: A describing function is a mathematical tool used in control theory to analyze nonlinear systems by approximating their behavior with a linear function. This method helps to simplify the analysis of systems that exhibit nonlinear characteristics, enabling engineers to use linear control techniques to predict system response and stability. By representing the nonlinear elements in a frequency domain, the describing function allows for a more manageable approach to understanding complex dynamic behaviors.
Feedback control: Feedback control is a process in which a system uses its output to adjust its input in order to maintain a desired performance or behavior. This technique helps systems adapt to changes or disturbances, ensuring stability and accuracy. By continuously monitoring the output and making adjustments based on that information, feedback control is crucial in the analysis and design of dynamic systems.
Fourier Series: A Fourier series is a way to represent a periodic function as a sum of simple sine and cosine functions. This powerful mathematical tool breaks down complex signals into their fundamental frequency components, making it easier to analyze and understand their behavior. Fourier series connect to various concepts in dynamic systems by providing insights into both homogeneous and non-homogeneous solutions, frequency response, and the transformations between time and frequency domains.
Frequency Response: Frequency response refers to the measure of a system's output spectrum in response to a sinusoidal input signal. It illustrates how different frequency components of the input signal are amplified or attenuated by the system, giving insight into the system's behavior across various frequencies.
Gain Margin: Gain margin is a measure of stability in control systems that indicates how much gain can be increased before the system becomes unstable. It is derived from frequency response analysis and provides insight into the robustness of a system's control, reflecting how close the system is to instability when subjected to changes in gain.
Holt's Approximation: Holt's Approximation is a method used to estimate the response of a dynamic system to sinusoidal inputs by simplifying the non-linear behavior into an equivalent linear approximation. This technique allows engineers to analyze systems that exhibit non-linear characteristics by providing a linearized view, which is essential for stability and frequency response analysis.
Laplace Transform: The Laplace transform is a mathematical technique that transforms a time-domain function into a complex frequency-domain representation. This method allows for easier analysis and manipulation of linear time-invariant systems, especially in solving differential equations and system modeling.
Limit Cycle: A limit cycle is a closed trajectory in phase space of a dynamic system that signifies periodic behavior, where the system eventually settles into this stable oscillation regardless of its initial conditions. This concept is crucial in understanding how nonlinear systems can exhibit sustained oscillations, leading to various applications in engineering and control theory. Limit cycles are significant because they indicate a system's response can be consistent over time, impacting stability and control strategies.
Nonlinear systems: Nonlinear systems are mathematical models in which the output is not directly proportional to the input, meaning that the relationship between variables involves nonlinear equations. These systems can exhibit complex behaviors like chaos, bifurcation, and hysteresis, making them significantly different from linear systems. Understanding these characteristics is essential when applying various mathematical modeling techniques, analyzing control strategies, and optimizing system performance.
Nyquist: Nyquist refers to a fundamental concept in signal processing and control theory that defines the relationship between the sampling rate and the bandwidth of a signal. It is crucial for ensuring that a system can accurately reconstruct a signal without aliasing, which is the distortion that occurs when the signal is inadequately sampled. This principle connects closely with analyzing stability and performance in control systems.
Oscillation prediction: Oscillation prediction refers to the process of forecasting the behavior of dynamic systems that exhibit oscillatory motion, allowing for analysis and control of systems such as mechanical oscillators and electronic circuits. By understanding the oscillation characteristics, such as frequency and amplitude, it becomes possible to anticipate system responses to various inputs and disturbances. This predictive capability is vital for maintaining stability and optimizing performance in systems prone to oscillations.
Phase margin: Phase margin is a measure of the stability of a control system, specifically indicating how close the system is to the verge of instability. It represents the difference in degrees between the phase angle of the open-loop transfer function and -180 degrees at the gain crossover frequency. A positive phase margin implies a stable system, while a negative value indicates instability, making it a crucial parameter in assessing system performance.
Piecewise linear function: A piecewise linear function is a mathematical function defined by multiple linear segments, each applicable over a specific interval of its domain. These functions are particularly useful in modeling systems that exhibit different behaviors across varying conditions or ranges, allowing for greater flexibility in analysis and representation of dynamic systems.
Routh: Routh refers to the Routh-Hurwitz stability criterion, a mathematical approach used to determine the stability of a linear time-invariant system by analyzing its characteristic polynomial. This method allows for the assessment of whether all roots of the polynomial have negative real parts, which is essential for ensuring that the system will respond to inputs without exhibiting unbounded growth over time. It provides a systematic way to ascertain stability without needing to calculate the roots directly.
Saturation nonlinearity: Saturation nonlinearity is a type of nonlinear behavior exhibited by systems when the output response reaches a limit or 'saturation' point, beyond which further increases in input do not result in proportional increases in output. This concept is crucial when analyzing dynamic systems, especially when using methods like describing functions, as it significantly affects the system's stability and performance under varying input conditions.
Stability limits: Stability limits refer to the boundaries within which a dynamic system can operate without losing stability. When a system is pushed beyond these limits, it may experience oscillations, diverging responses, or even failure. Understanding these limits is crucial for predicting system behavior and ensuring robust performance, especially when using methods like the describing function approach to analyze non-linear systems.
System stability analysis: System stability analysis is the process of determining whether a dynamic system will return to a steady state after being disturbed. This analysis is crucial for predicting how systems respond to changes in input or conditions, ensuring they remain reliable and functional over time.
