Broyden's method is a clever way to solve tricky math problems without doing all the hard work. It's like finding shortcuts in a maze. Instead of mapping out every turn, you make educated guesses based on what you've learned so far.

This method builds on what we've learned about solving equations, but with a twist. It's faster and uses less brain power than other methods, making it great for tackling big, complex problems in science and engineering.

Broyden's method for nonlinear equations

Concept and derivation

Top images from around the web for Concept and derivation

  • Broyden's method - Wikipedia View original

    Is this image relevant?

  • Convergence properties of the Broyden-like method for mixed linear–nonlinear systems of ... View original

    Is this image relevant?

  • Broyden's method - Wikipedia View original

    Is this image relevant?

1 of 3

Top images from around the web for Concept and derivation

  • Broyden's method - Wikipedia View original

    Is this image relevant?

  • Convergence properties of the Broyden-like method for mixed linear–nonlinear systems of ... View original

    Is this image relevant?

  • Broyden's method - Wikipedia View original

    Is this image relevant?

1 of 3
  • Broyden's method solves systems of without explicitly computing the
  • Approximates the Jacobian matrix using the relating function change to variable change
  • Derives update formula by minimizing of difference between current and previous Jacobian approximations, subject to secant condition
  • Uses to efficiently update inverse of Jacobian approximation in each iteration
  • Generalizes secant method for systems of equations
  • Maintains rate of Newton's method while reducing computational cost per iteration
  • Secant condition formula: Bk+1(xk+1−xk)=f(xk+1)−f(xk)B_{k+1}(x_{k+1} - x_k) = f(x_{k+1}) - f(x_k)
  • Broyden's update formula: Bk+1=Bk+(yk−Bksk)skTskTskB_{k+1} = B_k + \frac{(y_k - B_k s_k)s_k^T}{s_k^T s_k}
    • Where yk=f(xk+1)−f(xk)y_k = f(x_{k+1}) - f(x_k) and sk=xk+1−xks_k = x_{k+1} - x_k

Applications and advantages

  • Solves systems of nonlinear equations in various fields (engineering, physics, economics)
  • Particularly effective for problems with expensive function evaluations
  • Requires fewer function evaluations per iteration compared to Newton's method
  • Reduces memory requirements by storing only Jacobian approximation
  • Suitable for large-scale problems where explicit Jacobian computation becomes impractical
  • Examples of applications
    • Solving chemical equilibrium problems
    • Optimizing network flow in transportation systems
    • Finding roots of complex polynomial systems

Implementation and convergence of Broyden's method

Algorithm implementation

  • Initialize Jacobian approximation (identity matrix or finite differences)
  • Iteratively update solution and refine Jacobian approximation
  • Update formula for solution vector involves solving linear system using current Jacobian approximation
  • Solution update equation: xk+1=xk−Bk−1f(xk)x_{k+1} = x_k - B_k^{-1} f(x_k)
  • Implement criteria (check norm of function value or change in solution vector)
  • Pseudocode for basic Broyden's method:
Initialize x0, B0
While not converged:
    Solve Bk * sk = -f(xk) for sk
    xk+1 = xk + sk
    yk = f(xk+1) - f(xk)
    Bk+1 = Bk + (yk - Bk*sk) * sk^T / (sk^T * sk)

Convergence properties and improvements

  • Exhibits local and q-superlinear convergence under certain conditions
  • Convergence rate between linear and quadratic (superlinear with order 1 + √2)
  • Initial guess must be sufficiently close to solution for convergence
  • Incorporate safeguarding techniques to improve global convergence
    • (backtracking, Armijo rule)
    • (restrict step size based on model accuracy)
  • improves stability for ill-conditioned problems
  • Broyden-Fletcher-Goldfarb-Shanno (BFGS) method extends Broyden's idea to optimization problems

Broyden's method vs other nonlinear equation solvers

Comparison with Newton's method

  • Requires fewer function evaluations per iteration than Newton's method
  • Lower memory requirement (stores only Jacobian approximation)
  • Generally faster for problems with expensive function evaluations
  • Performance depends on problem structure and initial Jacobian approximation accuracy
  • Newton's method advantages
    • Quadratic convergence rate (faster near solution)
    • More robust for highly nonlinear problems
  • Broyden's method advantages
    • No need for explicit Jacobian computation
    • Lower computational cost per iteration

Comparison with other methods

  • Converges faster than fixed-point iteration methods (Picard iteration, successive substitution)
  • More robust than simple secant method for systems of equations
  • Less effective for highly nonlinear or ill-conditioned Jacobians
  • Hybrid approaches can outperform pure Broyden's method
    • (combines with Generalized Minimal Residual method)
    • (improves convergence for some problem classes)
  • Trade-offs between convergence speed, robustness, and computational cost per iteration
  • Examples of method selection criteria
    • Problem size (Broyden's for large-scale problems)
    • Function evaluation cost (Broyden's for expensive evaluations)
    • Jacobian structure (Newton's for sparse, easily computed Jacobians)

Key Terms to Review (27)

Anderson acceleration: Anderson acceleration is an iterative method used to improve the convergence of fixed-point iterations by combining information from several previous iterations to create a new approximation. This technique helps to overcome slow convergence rates often encountered in nonlinear equations, making it particularly useful in numerical methods like Broyden's method, which seeks to find solutions to systems of equations.
Broyden-Fletcher-Goldfarb-Shanno Method: The Broyden-Fletcher-Goldfarb-Shanno (BFGS) method is an iterative algorithm used for solving unconstrained optimization problems. It is a quasi-Newton method that updates an approximation of the inverse Hessian matrix at each iteration, improving convergence speed without requiring the computation of second derivatives. This makes it particularly effective in handling large-scale problems where computing the Hessian directly can be costly.
Broyden-GMRES Method: The Broyden-GMRES method is a numerical technique that combines Broyden's method for solving nonlinear equations with the Generalized Minimal Residual (GMRES) method for linear systems. This hybrid approach allows for efficient iterative solutions to large systems where the Jacobian matrix may not be explicitly known, leveraging Broyden's quasi-Newton updates alongside the GMRES framework to enhance convergence speed and accuracy.
Broyden's First Method: Broyden's First Method is an iterative algorithm used for finding the roots of a system of nonlinear equations. This method is part of a family of quasi-Newton methods that aim to approximate the Jacobian matrix without explicitly computing it, making it efficient for large-scale problems.
Broyden's Second Method: Broyden's Second Method is an iterative technique used to find solutions to systems of nonlinear equations. This method is a quasi-Newton approach that updates an approximate Jacobian matrix in a way that maintains its symmetry, aiming to improve convergence speed and reduce computational costs compared to other methods like Newton's method.
Charles G. Broyden: Charles G. Broyden was a British mathematician known for developing Broyden's method, which is an iterative algorithm used for solving nonlinear equations and optimization problems. His work laid the foundation for quasi-Newton methods, which are essential in numerical analysis for finding solutions to large-scale problems where traditional methods may be inefficient or impractical.
Convergence: Convergence refers to the process where a sequence, series, or iterative method approaches a specific value or solution as the number of iterations increases. This concept is crucial in numerical analysis because it determines how effectively and reliably methods can solve mathematical problems, ensuring that results become increasingly accurate as computations proceed.
Damped Broyden's Method: Damped Broyden's Method is an iterative algorithm used for solving nonlinear systems of equations. It modifies Broyden's method by introducing a damping factor to enhance convergence properties, making it more robust, particularly in cases where the original method may diverge or be slow to converge. This technique effectively balances the step size taken in each iteration, allowing for a more controlled approach towards the solution.
Economics modeling: Economics modeling refers to the theoretical frameworks and mathematical representations used to analyze economic behavior and predict outcomes based on various assumptions and variables. These models help economists understand complex relationships within economies, identify trends, and provide insights for decision-making and policy formulation.
Engineering optimization: Engineering optimization refers to the mathematical and computational techniques used to find the best possible solution to a problem, often by maximizing or minimizing a particular objective function while satisfying given constraints. This process is crucial in design and resource allocation, allowing engineers to make informed decisions that enhance efficiency and performance.
Finite difference approximation: Finite difference approximation is a numerical method used to estimate the derivative of a function by using the values of the function at specific discrete points. This technique converts differential equations into algebraic equations, making it easier to solve them numerically. Finite difference methods are widely applied in various fields such as physics, engineering, and finance to model complex systems and analyze their behavior over time.
Frobenius norm: The Frobenius norm is a matrix norm that measures the magnitude of a matrix by taking the square root of the sum of the absolute squares of its elements. It is similar to the Euclidean norm for vectors and is useful in optimization and numerical analysis, particularly when assessing convergence in methods like Broyden's method.
Iterative refinement: Iterative refinement is a process used to improve the accuracy of an approximate solution through repeated adjustments based on feedback from a mathematical model. This technique helps in honing in on the true solution by systematically updating the estimates and correcting errors at each step, making it particularly useful in optimization and root-finding algorithms.
Jacobian Matrix: The Jacobian matrix is a matrix that represents the first-order partial derivatives of a vector-valued function. It is essential in understanding how multivariable functions change and is particularly useful for analyzing nonlinear systems and optimizing functions. The Jacobian provides critical information about the behavior of these functions, including sensitivity and the local structure around points of interest.
Line Searches: Line searches are optimization techniques used to find a minimum (or maximum) along a specified direction in the context of a function. They are crucial in iterative methods for solving nonlinear equations and optimization problems, as they help determine the best step size to take in a given direction to minimize a cost function effectively. This approach is essential for methods like Broyden's method, where it optimally updates estimates to converge to the solution more efficiently.
Local linearization: Local linearization is the process of approximating a nonlinear function by a linear function near a specified point. This technique is particularly useful for understanding the behavior of functions in a small neighborhood around that point, allowing for easier analysis and computation. By using the derivative at that point, local linearization provides an effective means to simplify complex calculations involving nonlinear systems.
Nonlinear equations: Nonlinear equations are mathematical expressions in which the variables are raised to a power greater than one or multiplied together, causing the relationship between the variables to be non-proportional. Unlike linear equations, which graph as straight lines, nonlinear equations can create curves, circles, or more complex shapes. This complexity often requires specialized methods for solving them, especially when finding roots or intersections with other equations.
Positive Definite Matrices: Positive definite matrices are symmetric matrices with all positive eigenvalues, which implies that for any non-zero vector, the quadratic form associated with the matrix is always positive. This property is crucial in various mathematical and computational applications, particularly in optimization and numerical methods, as it ensures the uniqueness of solutions and stability in algorithms.
Quasi-newton methods: Quasi-Newton methods are optimization algorithms used to find the local minimum of a function by approximating the Hessian matrix, which is the matrix of second derivatives. These methods are particularly effective for problems where computing the Hessian is too expensive or impractical. They iteratively update an estimate of the inverse Hessian using gradient information, making them a popular choice for nonlinear systems of equations and other optimization tasks.
Root-finding problems: Root-finding problems involve determining the values of a variable that satisfy a given equation, specifically where the function equals zero. These problems are fundamental in numerical analysis and can be approached using various methods to find solutions efficiently. The accuracy and speed of these methods are crucial, especially in computational mathematics, where precise solutions are often required for more complex problems.
Secant Condition: The secant condition is a mathematical criterion used in optimization methods, particularly in the context of root-finding algorithms like Broyden's method. This condition ensures that the approximate solution iteratively improves by requiring the secant lines formed by two successive iterations to converge toward the true solution. It plays a key role in updating the Jacobian approximation and ensuring the algorithm maintains good convergence properties.
Sherman-Morrison Formula: The Sherman-Morrison formula is a mathematical result that provides a way to update the inverse of a matrix when a low-rank update is applied. It is particularly useful in computational mathematics for efficiently computing the inverse of a matrix that has been modified by adding or subtracting an outer product of vectors, making it relevant in iterative methods such as Broyden's method.
Superlinear convergence: Superlinear convergence refers to a property of iterative methods where the error decreases faster than linearly as the iterations progress, often leading to significant reductions in error with each step. This behavior indicates that the method is approaching the solution at an increasingly rapid rate, particularly when close to the solution. It is a desirable characteristic for numerical algorithms, as it can lead to fewer iterations needed to reach an acceptable level of accuracy.
Symmetric matrices: Symmetric matrices are square matrices that are equal to their transpose, meaning the elements across the diagonal are mirrored. This property implies that for any element in the matrix at position (i, j), it holds true that the element at position (j, i) is the same. Symmetric matrices are crucial in various numerical methods and optimization problems, as they often arise in the context of second-order derivative approximations and are easier to work with due to their inherent properties.
System of nonlinear equations: A system of nonlinear equations is a set of two or more equations in which at least one of the equations is nonlinear. These systems can be challenging to solve because they may have multiple solutions or no solution at all, depending on the relationships between the variables involved. Understanding how to approach these systems is crucial, especially when applying numerical methods like Broyden's method to find approximate solutions.
Trust Region Methods: Trust region methods are optimization techniques that create a restricted area around the current point in the search space where a model is trusted to approximate the objective function accurately. These methods balance local and global search by adjusting the size of the trust region based on how well the model predicts the behavior of the objective function, making them particularly useful in solving nonlinear optimization problems, nonlinear systems of equations, and when implementing methods like Broyden's for updating Jacobians.
Update formulas: Update formulas are mathematical expressions used to modify an approximation or estimate based on new information or feedback, essential in iterative methods for solving nonlinear equations. These formulas allow algorithms to refine their current solution iteratively, making adjustments that lead toward convergence on the true solution. In the context of specific methods, such as Broyden's method, these updates enhance efficiency and accuracy in finding roots of functions by dynamically adjusting an approximation of the Jacobian matrix.
